Limit Switch D4NA-4132 / D4N-4A72

The elevator limit switch d4na-4132-d4n-4a72 is part of the OMRON D4N safety series, designed for reliable position detection in machinery, including lift systems. These switches use a snap-action contact mechanism to provide accurate and consistent detection at critical points such as door zones and shaft positions. With robust housing rated to IP67, they withstand dust, water, and daily mechanical use. Suitable for UAE lift environments, the switches operate across a wide temperature range and are built for long-term mechanical durability.

Key Specifications:

• Series: OMRON D4N Safety Limit Switch
• Actuator: Roller plunger / Roller lever (depending on model)
• Contact form: 1NC/1NO
• Protection rating: IP67
• Operating temperature: –30°C to +70°C
• Mechanical durability: 15 million operations
• Mechanism: Snap-action contact
• Use points: Shaft positions, door zones, and other limit points
