Car top board: MCTC-CTB-A

Product Overview

The Monarch CTB-A car top board is a printed circuit board designed for installation on the lift car top. It forms part of the lift control system and supports safe operation during normal service and inspection mode.

This elevator car top control board manages signals from door units, limit switches, inspection controls, and safety circuits. It allows clear communication between car top devices and the main controller.

Installed on the car top, the board supports maintenance work by enabling engineers to control lift movement from the inspection station. Correct matching with the original lift control system is required to ensure stable performance and system safety.

Key specifications

• Product Name: Monarch CTB-A Car Top Board
• Product code: BS-PB0001
• Type: Elevator car top control PCB
• Application: Passenger and service lifts
• System Compatibility: Monarch lift control systems
• Installation Location: Lift car top
• Function: Signal control and communication between car top devices and main controller
• Material: Industrial-grade printed circuit board
• Operating Environment: Lift shaft environment (indoor use)

Note: Technical ratings such as voltage and current must be verified from the product label or official Monarch documentation before installation
