Levelling sensor: MKF71ASAKX

Product Overview

The MKF71ASAKX is a magnetic door zone sensor used in lift systems to confirm correct car position at each landing. It is also known as a door zone sensor. The unit works with a magnetic target fixed in the lift shaft. It detects the magnetic field and sends a signal to the control system when the lift car enters the door zone area.

The elevator MKF71ASAKX door zone sensor plays a key role in safe boarding and alighting. It helps the lift doors open only when the car is level with the floor. This reduces the risk of mis-levelling and supports smooth operation.

This model is used in commercial and residential lift systems where reliable floor detection is required.

Key specifications

• Product code: BS-SR0008
• Model: MKF71ASAKX
• Type: Magnetic door zone / levelling sensor
• Application: Elevator door zone detection
• Sensing method: Magnetic field detection
• Installation: Car-mounted, used with fixed magnetic target
• Output: Signal change when within door zone range
• Contact type: Non-contact sensing
• Use Case: Confirms correct floor level before door opening
