WECO Elevator Door Sensor 917A61

Product Overview

The WECO 917A61 Elevator Door Sensor is an infrared light curtain designed to provide full-height protection for elevator door openings. It uses multiple infrared beams to detect passengers, luggage, trolleys and other objects within the elevator doorway.

The sensor helps prevent elevator doors from closing when an obstruction is detected. Its non-contact detection system provides reliable door protection without mechanical contact with the detected object.

The WECO 917A61 consists of infrared sensor bars installed on both sides of the elevator door opening. It is suitable for elevator door safety applications and can be used for replacement, repair and maintenance of compatible lift door systems.

Before installation, verify the model, voltage, dimensions, door operator and control system compatibility with the existing elevator installation.

Key specifications

• Product Type: Elevator Door Sensor / Light Curtain
• Model: 917A61
• Model Version: 917A61-AC220
• Application: Elevator door safety and obstruction detection
• Detection Method: Infrared multi-beam sensing
• Input Voltage: 220V AC for AC220 version
• Scanning Beams: Up to 94 beams
• Protection Height: Approximately 20–1840 mm
• Mounting Type: Vertical mounting on both sides of the elevator door
• Application: Elevator and lift door systems
• Use: Replacement, repair and maintenance of compatible elevator door systems
